SKF 22213 EK/C3 Explorer Spherical Roller Bearing For Sale Online

This SKF Explorer spherical roller bearing has a steel cage, a C3 radial clearance, and a straight bore suitable for applications that support high radial and oscillating axial loads, such as in a belt conveyor system. The two-piece pressed steel window-type cage has high wear resistance, and it spaces the rollers for even load distribution and prevents contact to reduce friction, vibration, and noise. The bearing's straight bore fits conventional cylindrical shafts. This bearing has two rows of symmetrically arranged rollers oriented on a concave raceway, which allow self-realignment and compensate for static and dynamic alignment errors, and it has a maximum operating temperature of 392 degrees F. It meets International Standards Organization (ISO) standards for hardening of bearing rollers and rings. This spherical barrel roller bearing is suitable for use in material handling equipment, electric generators, and machine tools. Specifications Main bearing dimensionsDIN 635-2Basic dynamic load ratingsDIN ISO 281Dimensional and geometric tolerances DIN 620-2, (ISO 492) tolerance class PNSteel composition for inner and outer rings and rollersISO 683-17System for creating part numbersDIN 623-1Roller bearings use rolling elements to maintain the separation between moving parts to reduce rotational friction and support radial and axial loads. All roller bearings are open, shielded, or sealed. The shield protects the working parts of the bearing from environmental debris that may be introduced and could reduce the ball bearing speed and lifespan. Rolling bearings are used in a range of applications from agricultural machinery to conveying equipment, robotics, dental equipment, elevators, rolling mills, ship rudder shafts, and aggregate crushers, among others. Two row spherical roller bearing suitable for applications that support high radial and oscillating axial loads Two-piece pressed steel window-type cage has high wear resistance and spaces the rollers for even load distribution and prevents contact to reduce friction, vibration, and noise Flangeless inner ring with cage guide C3 radial clearance is larger than normal for applications where impact loads and vibration are severe, or thermal expansion is a factor
